Brand Name : | HBONY |
Model Number : | HBY-PJ460P |
Certification : | ISO9001, FCC, CCC, RoHS, CE |
Price : | negotiable |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability : | 3000pcs/month |
Delivery Time : | within 1 week |
Long Life Seamless Video Wall Lcd Monitors 46 Inch 500 Nits Brightness
Function
According to the user's requirements for input signals, different video processing systems can be selected to achieve VGA, composite video, S-VIDEO, YPBPR/YCBCR or DVI signal input, to meet the needs of different use occasions and different signal input. Through the control software, various signals can be switched, spliced into full-screen display, arbitrary combination display, image stretching display, image roaming display, image overlay display and so on.
Specification
Specification | |
Size | 46 inch |
Panel brand | Samsung |
Model No. | HBY-PJ460P |
Panel Size | 46" DID LCD module |
Backlight Type | LED |
Display Area | 1018.08(H)x572.67(v)mm |
Aspect Ratio | 16:9 |
Resolution | 1920X1080 |
Color | 8Bit,16.7M |
Brightness (nits) | 500cd/m2,700cd/m2 |
Contrast | 3500:1 |
Visual Angle (H/V) | 178°/178° |
Response Time | 8 ms |
Life Span | >60,000 hours |
Bezel width(between screens) | 1.7mm/3.5mm/5.5mm |
Product Weight | 20KG |
Interfaces (option 1- without 4K input) | |
Input | 1*DVI,1*HD-MI,1*VGA,2*BNC (PAL/NTSC),1*RS232(RJ45) |
Output | 2*RS232(RJ45),2*BNC (PAL/NTSC) |
Interfaces (option 2- With 4K input) | |
Input | 1*DVI,1*HDMI,1* DP (Display port),1*VGA (SVGA / XGA / WXGA),2*RS232(RJ45) |
Output | 1* DP (Display port),2*RS232(RJ45) |
Power | |
Power Supply | AC100V~240V 50/60Hz |
Maximum Power Consumption | 180W |
Standby Power Consumption | <1W |
Working Environment | |
Working Temperature | 0℃~50℃ |
Working Humidity | 10%-90%RH |
Packing
Special EPE pearl cotton is used for all-round shock-proof and impact-proof, and high-quality packing box ensures no damage in transportation.
![]() |
